Photo Opaque PVC with Hytrel™ Liner
EnviraLine™ composite tubing is commonly used for the conveyance of a wide variety of gases, including refrigerants and hydrocarbons. It has a unique co-extruded construction, incorporating a highly inert Hytrel® liner that exhibits excellent dielectric properties as well as superior barrier performance to nonpolar materials, even at elevated temperatures. Because Hytrel® has no plasticizers it does not outgas.
The product’s outer shell is comprised of a DEHP Free, permeable, photo opaque, black vinyl, allowing it to be repeatedly autoclaved without separation of the two materials. Because no ingredients contain Phthalates, EnviraLine™ meets REACH compliance. EnviraLine™ is also widely used in the welding industry for ground wire applications because of its dielectric properties.
Certifications:
Product Sizes
| ID (Inner Dia) | OD (Outer Dia) | Part Number | Wall Thickness |
|---|---|---|---|
| 1/8" | 0.22" | TT-PVH0.125-0.220BK | 0.048" |
| 0.17" | 1/4" | TT-PVH0.170-0.250BK | 0.04" |
| 0.17" | 0.314" | TT-PVH0.170-0.314BK | 0.072" |
| 0.188" | 0.275" | TT-PVH0.187-0.275BK | 0.044" |
| 1/4" | 3/8" | TT-PVH0.250-0.375BK | 0.063" |
| 1/4" | 0.438" | TT-PVH0.250-0.437BK | 0.094" |
| 0.28" | 0.469" | TT-PVH0.280-0.468BK | 0.094" |
| 3/8" | 1/2" | TT-PVH0.375-0.500BK | 0.063" |
| 1/2" | 5/8" | TT-PVH0.500-0.625BK | 0.063" |
| 1/2" | 0.688" | TT-PVH0.500-0.687BK | 0.093" |
| 1/2" | 3/4" | TT-PVH0.500-0.750BK | 0.063" |
